from 1,631.39 €
Quantity-tier prices are visible to registered companies.
No payment now. Transport is quoted after you place the order and needs your approval.
On-grid inverter Huawei SUN2000-30KTL-M3 rated 30 kW, three-phase, 4 MPPT. Max. DC voltage 1100 V, MPP voltage range 200 to 1000 V, maximum efficiency 98.7%, European efficiency 98.4%. IP rating IP65, operating temperature −25 to 60 °C, cooling: natural convection. Dimensions 640 × 530 × 270 mm (H × W × D), weight 43 kg, warranty 10 years.
| Series | SUN2000-30/36/40KTL-M3 |
|---|---|
| Product warranty | 10 years |
| Series AC power range | 33-44 kW |
| Max. DC voltage | 1100 V |
| Min. DC start-up voltage | 200 V |
| Max. DC current | 104 A |
| MPP voltage range | 200-1000 V |
| Strings per MPPT | 4 |
| DC inputs | 8 |
| Connectors | MC4 |
| Max. AC power | 33 kW |
| Nominal AC voltage | 230; 400; 480 V |
| Max. AC current | 47.9 A |
| Frequency | 50,60 Hz |
| Power factor | 0.8 |
| Maximum efficiency | 98.7 % |
| European efficiency | 98.4 % |
| Operating temperature range | -25 ~ +60 °C |
| IP rating | IP65 |
| Relative humidity | 0-100 % |
| Cooling | Natural convection |
| Max. altitude | 4000 m |
| Interfaces | RS 485, Ethernet, WLAN |
| Display | Led |
| Protection features | Anti Island Protection(ENS), Overcurrent Protection, Residual Current Device (RCD), Reverse Polarity Protection, Surge Protection |
| Inverter type | On-grid |
|---|---|
| Number of MPPT | 4 |
| Inverter power | 30 kW |
| Number of phases | 3 |
| Height | 640 mm |
|---|---|
| Width | 530 mm |
| Depth | 270 mm |
| Weight | 43 kg |
