Panasonic 5 kW WH-WDG05LE5 + WH-ADC0509L3E5AN

Power: 5 kW
Availability: On order
Minimum order: 1 pcs

Downloads

PDF Manufacturer datasheet 1.3 MB

Price on request

We will check availability and get back to you with this information.

Nothing to pay now.

Description

Air-to-water heat pump Panasonic WH-WDG05LE5 + WH-ADC0509L3E5AN with 5 kW heating capacity, refrigerant R290 (propane), compressor: inverter. SCOP 5.06 (W35), COP 5.05 (A7/W35), energy class A+++, seasonal space heating efficiency ηs 200% (W35). Max. flow temperature 75 °C, min. outdoor operating temperature −25 °C, power supply single-phase, SG Ready. Outdoor unit: 996 × 980 × 430 mm (H × W × D), 98 kg, sound power level 52 dB(A).

Technical data

Main parameters

Heating capacity	5 kW
Seasonal energy class (W35)	A+++
SCOP (average climate, W35)	5.06
Refrigerant	R290 (propane)
Heat pump type	Air-to-water
Grid readiness (SG Ready)	SG Ready
Seasonal space heating efficiency ηs (W35)	200 %

Product details

COP (A7/W35)	5.05
Cooling capacity	5 kW
Max. flow water temperature	75 °C
Min. outdoor operating temperature	-25 °C
Compressor type	Inverter
Refrigerant charge	0.96 kg
Refrigerant GWP	3
Number of phases	1
Rated power input (heating)	0.99 kW
COP (A-7/W35)	3.01
COP (A2/W35 or B0/W35)	3.52
Number of compressors	1
Max. power input	2.93 kW
Seasonal space heating efficiency ηs (W55)	142 %
Functions	Heating, cooling, DHW
Nominal water flow	0.86 m³/h
AC input voltage	220-240 V
Frequency	50 Hz

Dimensions and weight

Sound power level, outdoor unit (LwA)	52 dB(A)
Sound power level, indoor unit (LwA)	41 dB(A)
Outdoor unit weight	98 kg
Outdoor unit height	996 mm
Outdoor unit width	980 mm
Outdoor unit length	430 mm
