Panasonic 12 kW WH-UQZ12KE8 + WH-SXC12K9E8

Power: 12 kW
Availability: On order
Minimum order: 1 pcs

Downloads

PDF Manufacturer datasheet 0.5 MB

Price on request

We will check availability and get back to you with this information.

Nothing to pay now.

Description

Air-to-water heat pump Panasonic WH-UQZ12KE8 + WH-SXC12K9E8 with 13 kW heating capacity, refrigerant R32, compressor: inverter. SCOP 4.44 (W35), COP 4.84 (A7/W35), energy class A+++, seasonal space heating efficiency ηs 175% (W35). Power supply three-phase, SG Ready. Dimensions 892 × 500 × 348 mm (H × W × D), weight 41 kg, outdoor unit sound power level 58 dB(A).

Technical data

Main parameters

Heating capacity	13 kW
Seasonal energy class (W35)	A+++
SCOP (average climate, W35)	4.44
Refrigerant	R32
Heat pump type	Air-to-water
Grid readiness (SG Ready)	SG Ready
Seasonal space heating efficiency ηs (W35)	175 %

Product details

COP (A7/W35)	4.84
Cooling capacity	10 kW
Compressor type	Inverter
Refrigerant charge	1.6 kg
Refrigerant GWP	675
Number of phases	3
Rated power input (heating)	2.69 kW
COP (A-7/W35)	2.73
COP (A2/W35 or B0/W35)	4.65
Number of compressors	1
Max. power input	7.6 kW
Seasonal space heating efficiency ηs (W55)	131 %
Functions	Heating, cooling
AC input voltage	380-415 V
Frequency	50 Hz
