PV module SunLink SL5N108 rated 455 Wp. Cells: N-type, bifacial, black frame, module efficiency 22.8% (STC). Product warranty 15 years, power warranty: 87.4% after 30 years. Dimensions 1762 × 1134 × 30 mm (H × W × D), weight 23 kg.
| Series | SL5N108 450-455 |
|---|---|
| Series power range | 450-455 Wp |
| Warranty | 15 years |
| Power warranty — point 2 (years, % output) | 30, 87.4 |
| Voltage at max. power Vmpp (STC) | 32.99 V |
| Current at max. power Impp (STC) | 13.79 A |
| Open-circuit voltage Voc (STC) | 40.1 V |
| Short-circuit current Isc (STC) | 14.58 A |
| Module efficiency (STC) | 22.8 % |
| Operating temperature range | -40 ~ 85 °C |
| Temperature coefficient of Pmax | -0.3 %/°C |
| Temperature coefficient of Voc | -0.26 %/°C |
| Temperature coefficient of Isc | 0.046 %/°C |
| Max. system voltage | 1500 V |
| Max. series fuse rating | 25 A |
| Number of cells | 108 |
| Frame | Anodised aluminium alloy |
| Bypass diodes | 3 |
| Junction box IP rating | IP68 |
| Connector type | MC4 compatible |
| Cable cross-section | 4 mm² |
| Cable length | (+) 380, (-) 380 or customized length mm |
| Module power | 455 Wp |
|---|---|
| Cell type | N-type |
| Frame colour | Black frame |
| Module type | Bifacial |
| Height | 1762 mm |
|---|---|
| Width | 1134 mm |
| Depth | 30 mm |
| Weight | 23 kg |
