Victron 3 kW Phoenix Inverter 48/3000 VE.Bus

Moc: 3 kW
Fazy: 1‑fazowy
Dostępność: Na stanie
: Liczba ofert: 11
Minimalne zamówienie: 1 szt.

Do pobrania

PDF Karta katalogowa — victron-c483000-phoenix-inverter-compact-1200va-2000va 0,7 MB

Cena netto wg ilości

od 437,26 €

Ceny w progach ilościowych widoczne są dla zarejestrowanych firm.

Teraz nic nie płacisz. Koszt transportu wyceniamy po złożeniu zamówienia; wymaga on Twojej akceptacji.

Opis

Falownik wyspowy (off-grid) Victron Phoenix Inverter 48/3000 VE.Bus o mocy 3 kW, jednofazowy. Maks. napięcie DC 66 V, sprawność maksymalna 95 %. Stopień ochrony IP65, zakres temperatury pracy od −40 do 65 °C. Wymiary 362 × 258 × 218 mm (wys. × szer. × gł.), waga 18 kg.

Informacje producenta

Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimized efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact. SinusMax - Superior engineering Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimized efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem-free, to any load. These larger Phoenix inverter models come with a VE.Bus port. All you need to connect to your PC is our MK3- USB VE.Bus to USB interface (see under accessories). Together with our VictronConnect or VEConfigure software, which can be downloaded free of charge from our website, parameters of the inverters can be customized. This includes output voltage and frequency, over and under voltage settings and programming the relay. This relay can for example be used to signal several alarm conditions, or to start a generator. The inverters can also be connected to a GX device (eg Cerbo GX) for monitoring and control. dimensions, light in weight and capable of supplying power, problem-free, to any load.

Dane techniczne

Szczegóły produktu

Seria	Phoenix Inverter Compact 1200VA - 2000VA
Gwarancja produktowa	5 upgradable to 10 lat
Zakres mocy AC serii	2,4-10 kW
Maks. napięcie DC	66 V
Maks. moc AC	3 kW
Napięcie znamionowe AC	230 V
Zakres częstotliwości	45-55 Hz
Częstotliwość	50 Hz
Sprawność maksymalna	95 %
Zakres temperatury pracy	-40 ~ +65 °C
Stopień ochrony (IP)	IP65
Wyświetlacz	LED
Zabezpieczenia	Short Circuit Protection, Overload Protection, Overvoltage Protection, Overtemperature Protection
