Victron 3 kW 3 kVA 24/3000

Moc: 3 kW
Fazy: 1‑fazowy
Dostępność: Na stanie
: Liczba ofert: 10
Minimalne zamówienie: 1 szt.

Do pobrania

PDF Karta katalogowa — victron-3-kva-243000-phoenix-inverters-3-kva 0,6 MB

Cena netto wg ilości

od 689,34 €

Ceny w progach ilościowych widoczne są dla zarejestrowanych firm.

Teraz nic nie płacisz. Koszt transportu wyceniamy po złożeniu zamówienia; wymaga on Twojej akceptacji.

Opis

Falownik wyspowy (off-grid) Victron 3 kVA 24/3000 o mocy 3 kW, jednofazowy. Maks. napięcie DC 33 V, sprawność maksymalna 94 %. Stopień ochrony IP65, zakres temperatury pracy od −40 do 65 °C. Wymiary 362 × 258 × 218 mm (wys. × szer. × gł.), waga 18 kg.

Informacje producenta

Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem free, to any load. A unique feature of the SinusMax technology is very high start-up power. Conventional high frequency technology does not offer such extreme performance. Phoenix inverters, however, are well suited to power up difficult loads such as refrigeration compressors, electric motors and similar appliances. Up to 6 units inverters can operate in parallel to achieve higher power output. Six 24/3000 units, for example, will provide 15 kW / 18 kVA output power. Operation in 3-phase or split phase configuration is also possible. If an automatic transfer switch is required we recommend using the MultiPlus inverter/charger instead. The switch is included in these products and the charger function of the MultiPlus can be disabled. Computers and other electronic equipment will continue to operate without disruption because the MultiPlus features a very short switchover time (less than 20 milliseconds). These larger Phoenix inverter models come with a VE.Bus port. All you need to connect to your PC is our MK3- USB VE.Bus to USB interface (see under accessories). Together with our VictronConnect or VEConfigure software, which can be downloaded free of charge from our website, parameters of the inverters can be customized. This includes output voltage and frequency, over and under voltage settings and programming the relay. This relay can for example be used to signal several alarm conditions, or to start a generator. The inverters can also be connected to a GX device (eg Cerbo GX) for monitoring and control.

Dane techniczne

Szczegóły produktu

Seria	Phoenix Inverters 3 kVA
Gwarancja produktowa	5 upgradable to 10 lat
Zakres mocy AC serii	6 kW
Maks. napięcie DC	33 V
Maks. moc AC	3 kW
Napięcie znamionowe AC	120 V
Częstotliwość	60 Hz
Sprawność maksymalna	94 %
Zakres temperatury pracy	-40 ~ +65 °C
Stopień ochrony (IP)	IP65
Wyświetlacz	LED
Zabezpieczenia	Short Circuit Protection, Overload Protection, Overvoltage Protection, Overtemperature Protection
