V-TAC 40,96 kWh VT-OHS40K-100 120028

V-TAC 40,96 kWh VT-OHS40K-100 120028

Kapazität
41,0 kWh
Verfügbarkeit
Auf Lager
Anzahl der Angebote: 1
Mindestbestellung
1 Stk.
Incoterms
CIF

Nettopreis nach Menge

ab 7 942,00 €

Staffelpreise sind für registrierte Unternehmen sichtbar.

Keine Zahlung jetzt. Der Transport wird nach der Bestellung kalkuliert und von Ihnen freigegeben.

Beschreibung

Batterieset V-TAC VT-OHS40K-100 120028 mit 40,96 kWh Kapazität (8 Module), LiFePO4 (LFP), Hochvolt (HV), Spannung 409,6 V. Kommunikation CAN, Schutzart IP65, Entladetiefe 80 %. Anwendung: Gewerbe und Industrie (C&I). Abmessungen 1453 × 420 × 590 mm (H × B × T), Gewicht 389,4 kg, Garantie 10 Jahre.

Herstellerangaben

Smaller Footprint higher energy density benefit from latest LFP technology Expandable Module design Maximum 5.12kwh*10S*6P Monitor Real-time monitoring of battery charging and discharging, online system updates and maintenance

Technische Daten

Produktdetails

SerieStackable LiFePo4 Battery System
Garantie10 Jahre
Anzahl Batteriemodule8
Entladetiefe (DoD)80 %
Schutzart (IP)IP65
KommunikationsprotokollCAN
Systemtyp (HV / LV)Hochvolt (HV)

Hauptparameter

Kapazität40,96 kWh
Batteriespannung409,6 V
ZellentechnologieLiFePO4 (LFP)
AnwendungGewerbe und Industrie (C&I)

Maße und Gewicht

Höhe1453 mm
Breite420 mm
Länge590 mm
Gewicht389,4 kg
