Fronius 100 kW 100-3-P

Fronius 100 kW 100-3-P

Leistung
100 kW
Phasen
3‑phasig
Verfügbarkeit
Auf Lager
Anzahl der Angebote: 2
Mindestbestellung
1 Stk.
Incoterms
CIF, EXW, FCA

Downloads

Nettopreis nach Menge

ab 4 840,00 €

Staffelpreise sind für registrierte Unternehmen sichtbar.

Keine Zahlung jetzt. Der Transport wird nach der Bestellung kalkuliert und von Ihnen freigegeben.

Beschreibung

Netzgekoppelter Wechselrichter (On-Grid) Fronius 100-3-P mit 100 kW Nennleistung, dreiphasig, 1 MPP-Tracker. Max. DC-Spannung 1000 V, max. Wirkungsgrad 98,5 %, europäischer Wirkungsgrad 98,2 %. Schutzart IP65, Betriebstemperatur −40 bis 65 °C. Abmessungen 755 × 1109 × 346 mm (H × B × T), Gewicht 103 kg, Garantie 5 Jahre.

Herstellerangaben

01 Robust and durable Designed to buck direct sunlight and high temperatures: its double-walled housing and active cooling give the Fronius Tauro a long service life and make it a robust commercial solar inverter that will always deliver top performance. 02 Lower costs and efficient servicing For minimal overall system operating costs: Fronius Tauro is quick to install and efficient to maintain. When servicing is required, only the affected power stage set needs to be replaced rather than the entire project inverter. This makes for safe operation and fast, cost-efficient servicing. 03 Intelligent control and an open system Like all Fronius products, Fronius Tauro can be conveniently monitored, controlled and maintained from a smartphone or PC. Fronius Solar.web lets you keep an eye on your system at all times. Its open system architecture means third-party components are easily integrated. 04 Design flexibility Centralised, decentralised, vertical or horizontal: Fronius Tauro offers you maximum flexibility in the design and installation of large-scale PV systems. The flexible Tauro and the cost-effective Tauro ECO can be combined in any way you choose. Pre-integrated surge protection device and AC daisy chaining reduce the need for additional components and cables. 05 Repairable and sustainable Fronius Tauro shows that sustainability at every stage of the product cycle pays dividends. The project inverter is designed for durability and was developed and produced in Austria with the fewest possible, replaceable components. This makes the Tauro particularly robust and failure-resistant, and means that only individual parts need to be replaced during on-site servicing, thereby saving time and conserving resources.

Technische Daten

Produktdetails

SerieTauro ECO
Produktgarantie5 Jahre
AC-Leistungsbereich der Serie50-100 kW
Max. DC-Leistung150 kW
Max. DC-Spannung1000 V
Max. DC-Strom175 A
Strings pro MPP-Tracker1
Max. AC-Leistung100 kW
AC-Nennspannung380-400 V
Max. AC-Strom151.5/144.9 A
Frequenzbereich45-65 Hz
Frequenz50/60 Hz
Leistungsfaktor0–1 (induktiv / kapazitiv)
Max. Wirkungsgrad98,5 %
Europäischer Wirkungsgrad98,2 %
Betriebstemperaturbereich-40 ~ +65 °C
Schutzart (IP)IP65
SchutzfunktionenInternal Overvoltage Protection DC Insulation Rsistance Detection Grid Monitoring GFCI Monitoring DCI Monitoring AC Short Circuit Current Protection AC Grounding Detection DC Surge Protection AC Surge Protection Anti-islanding Protection AFCI Protection

Hauptparameter

WechselrichtertypNetzgekoppelt (On-Grid)
Anzahl MPP-Tracker1
Wechselrichterleistung100 kW
Phasenzahl3

Maße und Gewicht

Höhe755 mm
Breite1109 mm
Tiefe346 mm
Gewicht103 kg
